Overview: Axle & Drive Shaft Maintenance & Repair
A lot of driveline work in Britain starts with an MOT sheet. A CV boot that's split and letting dirt in is a major defect, and so is an excessively worn joint or shaft bearing. Either one means a fail. Plenty of owners only find out the boot has gone when the tester shows them.
The noises still help. A click on full lock in a supermarket car park is usually an outer CV joint. A clunk as you pull away often means a worn universal joint. A vibration that builds at one motorway speed and fades above it points to a propshaft out of balance or a tired centre bearing.
Rear-wheel-drive saloons, four-wheel-drive estates and vans often run two-piece propshafts. Those need balancing on a machine, which is why many garages send the shaft to a specialist. Whoever does the job, the Consumer Rights Act expects it done with reasonable care and skill.
Our listings show what each specialist states on its own website about propshafts, driveshafts and diffs. The region and town lists below lead to specialists near you.
Cost of driveshaft and CV joint repairs in the UK
Compare a boot, joint or complete shaft for the same side of the vehicle.
| Job or scenario | Indicative cost | What the price covers |
|---|---|---|
| Driveline noise or vibration diagnosis | £70–£120per session | An initial noise or vibration assessment with an agreed inspection or road-test allowance. Dismantling and repair are separate. |
| Outer CV boot: worked small-car estimate | £160–£190per boot | Calculated example for one outer boot kit and 1.8 hours of straightforward fitting while the joint remains serviceable. A noisy or contaminated joint needs a separate assessment.This uses a retail kit price and published labour rates. The garage’s parts price, access and any extra damage can change the total. |
| Outer CV joint: worked small-car estimate | £210–£240per joint | Calculated example for one budget outer joint kit, including boot and grease, with 2.2 hours of straightforward fitting. Ask whether replacing the complete shaft would be better value for your car.This uses a retail kit price and published labour rates. The garage’s parts price and access can change the total; compare a joint-only and a complete-shaft quote. |
| Complete driveshaft replacement | £230–£400per side | One front driveshaft supplied and fitted on a mainstream car. State any gearbox oil, seals and exchange deposit separately. |
| Propshaft repair and balancing | Quote for the identified propshaft repair and balancingper assessed shaft | Identify centre bearing, couplings or joints, balancing and whether removal/refitting is included. |
What changes the price
- Boot-only, joint-only or complete-shaft repair.
- Front-wheel drive versus rear-wheel or four-wheel-drive propshaft work.
- Part availability, access and new or reconditioned units.
Ask before booking
- Is the failed part the boot, the CV joint or the complete shaft?
- Does the quote cover one side, and include seals, fittings and any fluid replacement?
- For a propshaft, are balancing, removal, refitting and warranty included?
Ask why a complete shaft is recommended and whether a joint or boot repair is technically suitable.
A wheel driveshaft and a rear-wheel or four-wheel-drive propshaft are different assemblies.
Frequently asked questions
Will a split CV boot fail the MOT?
Yes, if the split lets dirt in. The MOT manual lists a CV boot that's missing, split or insecure and no longer keeps dirt out as a major defect, so the car fails. A boot that's badly perished but still sealed is a minor defect, and the car can pass with it noted. Treat that note as a deadline. A new boot now costs far less than a joint later.
Split boot: repack it or replace the shaft?
If the gaiter has only just split and the grease inside still looks clean, a new gaiter and fresh grease will do. Once grit has scored the joint, sealing it up just traps the damage. Then it's a new joint or an exchange driveshaft, and many garages fit the whole shaft because the labour barely changes. Ask whether the shaft is new or remanufactured, and what warranty it carries.
What causes a vibration only at certain speeds?
Rule out the wheels first. A pothole can bend an alloy just enough to shake the car at motorway speed, and a lost balance weight feels much the same. If the wheels check out, the driveline is next: a propshaft out of balance, a worn universal joint, or a centre bearing whose rubber has perished. A vibration that changes the moment you lift off points to the driveline.
Why does a drive shaft need balancing?
A propshaft turns fast, so any weight off centre becomes a shake you feel through the floor. Shafts leave the factory balanced with small welded weights. They lose that when the shaft is repaired, shortened or clouted by debris. A bent or badly damaged shaft is a major MOT defect in its own right. Balancing needs a machine that most garages don't have, so the shaft goes to a specialist.
What can I do if a propshaft repair goes wrong?
Tell the garage in writing and give it a fair chance to put things right. Under the Consumer Rights Act, work that wasn't done with reasonable care and skill should be redone at the garage's cost. If that can't happen in a reasonable time, you can ask for money off. If the garage is accredited by The Motor Ombudsman, you can take the dispute there for free.
